T-UV Thermal CTP Plate


ItemDescription
 Plate Non-ablative thermal positive long run plate. Optional post baking for extremely long run with normal and UV inks.
 Gauge 0.15 / 0.20 / 0.30 mm (0.24 & 0.40 mm on request)
 Coating Color Blue
 Spectra Sensitivity 800-850 nm
 Platesetter Compatibility Kodak Trendsetter, Kodak Lotem, Kodak Magnus, Screen PT-R, Heidelberg Topsetter, Suprasetter and Luescher Xpose
 Laser Energy 110 - 150 mJ/cm2
 Resolution 1% - 99% @ 200 lpi
 FM Capability 20 micron stochastic
 Processors Any suitable processor for thermal positive plate
 Developer TOP THP-8
 Processing 30 +/- 5 seconds dwell time at temperature 22 ~ 25 ℃
 Post Baking Conditions
  • Apply baking gum before baking
  • Static Oven: 220 - 230 ℃ for a duration of 5 - 8 minutes
  • Online Oven: 260 - 280 ℃ for a duration of 4 - 6 minutes (Actual oven settings may vary according to oven conditions)
 Runlength
  • Up to 120,000 impressions unbaked. 800,000 impressions after post baking.
  • Up to 20,000 impressions in UV applications unbaked. (Actual runlength may vary according to press, ink and paper conditions)
 Safelight 2 hours under white light
 Shelf life 12 months under recommended storage conditions
 Packaging Available in all standard formats, including bulk and Auto Pallet Loader (APL) formats.
 Transport and Storage Unopened plate packs should be stored flat and away from excessive cold, heat and humidity. Store in a controlled environment of 15 - 27 ℃ and 40% - 65% RH, non-condensing.
